LPG Vapor 90 Degree Air Inlet 345CFM Impco 200 Mixer

Ask Lasest Price
Brand Name :	IMPCO
Model Number :	Model 200
Certification :	UL
Payment Terms :	T/T
Supply Ability :	1200pcs per 8weeks
Delivery Time :	8 weeks
Price :	Depending on quantity

Add to Cart

Product Details
Company Profile

LPG Vapor 90 Degree Air Inlet 345CFM Impco 200 Mixer

IMPCO Mixer Model 200 , Single Diaphragm Air-Valve , 90° Air Inlet , Airflow 345 CFM

Model 200

DESCRIPTION

The Model 200 is a single diaphragm air-valve carburetor/mixer. It offers a 90° air inlet to provide low overhead clearance, and is available with several air horn and throttle valve options. This unit is available for LPG Vapor or Natural Gas for applications with airflow requirements up to 345 CFM (162.8 L/s). All DG model mixers reduce airflow by 30%.

The Model 200 is also available for feedback applications with the ’FB’ designation. The 200 mixer provides a convenient 1/8” balance port at the air inlet. Additional low speed idle mixture control can be obtained to lean air/fuel mixtures through the use of optional shims.

SPECIFICATIONS
Fuel Type	LPG Vapor or Natural Gas
Inlet Pressure	-1.5” w.c. (-0.37 kPa)
Operating Temperature Range	-40ºF to +250ºF (-40ºC to 121ºC)
Mounting Position	Vertical
Diaphragm Material	Hydrin (Standard), Silicone (Optional)
HP/kW Rating	172 hp (128.0 kW) @ 276 CFM (130 L/s) and 1.5” Hg manifold depression 215 hp (160.3 kW) @ 345 CFM (162.8 L/s) and 2.0” Hg manifold depression
