    Natural Gas 680CFM IMPCO Large Engine Mixers

    Ask Lasest Price
    Brand Name : IMPCO
    Model Number : 200T-1
    Certification : UL
    Payment Terms : T/T
    Supply Ability : 1200pcs per 8weeks
    Delivery Time : 8 weeks
    • Product Details
    • Company Profile

    Natural Gas 680CFM IMPCO Large Engine Mixers

    IMPCO Large Size Engine Carburetor 200T-1 , Triple Diaphragm Air-Valve , LPG Vapor, Natural Gas Applications
    IMPCO Large Engine Mixer Model 200T A Triple Diaphragm Air-Valve Carburetor/Mixer. LPG Vapor, Natural ,And Digester Gas
    Model 200T-1 is a triple diaphragm air-valve mixer with specified throttle body and air horn.This unit is available for LPG Vapor, Natural Gas applications with airflow requirements up to 680 CFM.
    SPECIFICATIONS
    Fuel TypeLPG Vapor, Natural Gas, or Digester/Landfill Gas
    (550 - 2,500 BTU)
    Inlet Pressure-1.5” w.c.
    Operating Temperature Range-40ºF to +250ºF
    Mounting PositionVertical
    Diaphragm MaterialHydrin (Standard), Silicone (Optional)
    HP/kW Rating316.9 kW @ 320.9 L/s and 2.0” Hg manifold depression
