Vertical Mounting 600hp Model 600D Impco Gas Mixer

Ask Lasest Price
Brand Name :	IMPCO
Model Number :	600-1
Certification :	UL
Price :	Depending on quantity
Payment Terms :	T/T
Supply Ability :	1200pcs per 8weeks
Delivery Time :	8 weeks

Add to Cart

Product Details
Company Profile

Vertical Mounting 600hp Model 600D Impco Gas Mixer

IMPCO Large Size Carburetor 600-1 , Concentric Flow Air Valve Type , LPG Vapor, Natural Gas, Landfill And Digeste Gas

IMPCO Large Engine Mixer Model 600D Is A Concentric Flow Type Air Valve Mixer LPG, Natural, Landfill And Digester Gases

The 600 is a gaseous fuel carburetor of the concentric flow air valve type. This mixer is suitable for LPG Vapor, Natural Gas, Landfill and Digester gases for applications requiring up to 960 CFM (453.1 L/s). A precision gas metering valve is attached to the air valve. Both the air and gas valve motions are linear in relation to volumetric flow. The air/fuel ratio is controlled by the adjustable power valve, shape of the gas metering valve, and the pressure from the gas regulator. Gas valves are shaped to provide A/F ratio versus flow characteristics defined by the fuel composition.

SPECIFICATIONS
Fuel Type
LPG Vapor	90% + Propane
Natural Gas	85% + Methane
Digester Gas	56-72% Methane
Landfill Gas	45-56% Methane
Inlet Pressure	+5.0” w.c. (1.24 kPa) over Air Inlet (Idle Setting)
Operating Temperature Range	-40°F to +250°F (-40°C to +121°C)
Mounting Position	Vertical
HP/kW Rating	600hp (447.0 kW) @ 960 CFM (453.1 L/s) and 2.0” Hg manifold depression
