| Ask Lasest Price | |
| Brand Name : | IMPCO |
| Model Number : | MODEL E&PE |
| Certification : | UL |
| Price : | Depending on quantity |
| Payment Terms : | T/T |
| Supply Ability : | 1200pcs per 8weeks |
| Delivery Time : | 8 weeks |
| SPECIFICATIONS | |
| Fuel Type | LPG Liquid/Vapor and Natural Gas |
| Inlet Pressure | |
| Maximum | 312 psi (21.51 Bar) |
| Minimum | 30 psi (207 kPa) |
| Outlet Pressure (Nominal) | |
| EB | -1.5” w.c. (-0.37 kPa) |
| EO | -5.0” w.c. (-0.12 kPa) |
| PE | +5.0” w.c. (1.2 kPa) |
| HP/kW Rating | 325 hp (242.3 kW) LPG 200 hp (150 kW) where lower water flow-rate is a factor. |
| Operating Temperature Range | -40°F to +250°F (-40°C to +121°C) |
| Fuel Filtration Required | 40 micron |
| Heating Chamber Source | Required for liquid LPG |
| Mounting Position | Vertical (outlet down) recommended. Horizontal position can be used when fuel contamination can be controlled with HD-5 specified LPG fuel |
| Diaphragm Material | Hydrin, Silicone, and Fluorosilicone (optional) |
| Applications | Stationary, mobile, industrial, and automotive |
| Certification | UL (AU2317 & AU1502), Inquire for specific ECE approval |
|
|
