LPG Vapor Aluminum IMPCO T52 Low Pressure Regulator

IMPCO Model T52 , Single Stage Secondary Regulator , LPG Or Natural Gas. A Vacuum Lockoff, Mechanical Primer

Model T52

DESCRIPTION

The Model T52 is a single stage secondary regulator suitable for LPG Vapor or Natural Gas. Variations of the regulator include a vacuum lockoff, mechanical primer and new mounting tabs. The T52 regulator is completely rebuildable using an IMPCO repair kit.

SPECIFICATIONS
Fuel Type	LPG Vapor or Natural Gas
Inlet Pressure(Maximum)
T52B	5.0 psi (34.5 kPa)
T52N	14.0” w.c. (3.45 kPa)
Outlet Pressure (Nominal)	-0.5” w.c. (-0.12 kPa)
HP/kW Rating
T52B	40 hp (29.8 kW) LPG Vapor
T52B	25 hp (18.6 kW) Natural Gas
T52N	15 hp (11.2 kW) LPG Vapor
T52N	12 hp (8.9 kW) Natural Gas
Operating Temperature Range	-40°F to +250°F (-40°C to +121°C)
Heating Chamber Source	None Required
Mounting Position	Vertical (outlet down) recommended. Horizontal position can be used when fuel contamination can be controlled with HD-5 or HD-10 specified LPG fuel.
Diaphragm Material	Hydrin
Applications	Mobile, stationary, and industrial
Certification	UL (AU2317 & AU1502), Inquire for specific ECE approval
