    Aluminum 242.4 KW IMPCO Model L Converter Fuel System Parts

    Ask Lasest Price
    Brand Name : IMPCO
    Model Number : MODEL L Regulator
    Certification : UL
    Payment Terms : T/T
    Supply Ability : 1200pcs per 8weeks
    Delivery Time : 8 weeks
    Price : Depending on quantity
    • Product Details
    • Company Profile

    Aluminum 242.4 KW IMPCO Model L Converter Fuel System Parts

    IMPCO Model L , Two Stage Regulator. Up To 242.4 KW Peak Or 149.1 KW Continuous , One Negative Outlet Pressure
    Model L
    DESCRIPTION
    The Model L is a two stage regulator/vaporizer. These units are coolant heated and are able to provide liquid vaporization to supply up to 325 hp (242.4 kW) peak or 200 hp (149.1 kW) continuous in industrial engine applications. The Model L regulator provides a negative outlet pressure of -1.5” w.c. (-0.37 kPa). No optional pressures are available. The Model L offers economical performance with full features; rear fuel inlet, and primary and secondary diagnostic test ports. Optional silicone diaphragm materials are also available.
    SPECIFICATIONS
    Fuel TypeLPG Liquid/Vapor
    Inlet Pressure
    Maximum312 psi (21.51 Bar)
    Minimum30 psi (207 kPa)
    Outlet Pressure (Nominal)-1.5” w.c. (0.37 kPa)
    HP/kW Rating325 hp (242.4 kW) peak, 200 hp (149.1 kW) continuous
    Operating Temperature Range-40°F to +250°F (-40°C to +121°C)
    Fuel Filtration Required40 micron
    Heating Chamber SourceRequired for liquid LPG
    Mounting PositionVertical recommended. Horizontal position can be used when fuel contamination can be controlled with HD-5 or HD-10 specified LPG fuel.
    ApplicationsMobile, industrial and automotive
    CertificationUL (AU1502), Inquire for specific ECE approval
